Lens
FILTER DIAMETER49 mm
General
CAMERA TYPEDigital camera
Lens
FOCUS RANGE (FROM THE FRONT OF THE LENS)Approx. 24 cm (0.8 ft.) to infinity (Normal mode), approx. 14 cm (0.46 ft.) to 29 cm (0.95 ft.) (Macro mode)
Lens
F-NUMBER (MAXIMUM APERTURE)F2
f = 35 mm
Camera Section
NUMBER OF PIXELS (TOTAL)Approx. 62.5 megapixels
SENSOR TYPE35mm full frame (35.7 x 23.8 mm), Exmor R CMOS sensor
BUILT-IN ND FILTER-
COLOR TEMPERATURE RANGE2500 K - 9900 K
NUMBER OF PIXELS (EFFECTIVE)Still images: Approx. 61.0 megapixels max.[FN_XX1], Movies: Approx. 50.8 megapixels max.[FN_XX1]
OPTICAL LOW PASS FILTER-
Recording (still images)
IMAGE SIZE (PIXELS) [3:2]35mm full frame L: 9504 x 6336 (60 M), M: 6640 x 4432 (29 M), S: 4752 x 3168 (15 M)
RECORDING FORMATJPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 5.0 format compliant)
Recording (movie)
AUDIO RECORDING FORMATLPCM 4ch (48 kHz 24 bit)1, LPCM 2ch (48 kHz 24 bit)1, LPCM 2ch (48 kHz 16 bit)
VIDEO COMPRESSIONXAVC S: MPEG-4 AVC/H.264
Recording System (movie)
MOVIE RECORDING FORMAT (XAVC S 4K)3840 x 2160 (4:2:0, 8bit) (Approx.): 29.97p (100 Mbps / 60 Mbps), 25p (100 Mbps / 60 Mbps), 23.98p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:2, 10bit) (Approx.): 29.97p (140 Mbps), 25p (140 Mbps), 23.98p (100 Mbps)
MOVIE RECORDING FORMAT (XAVC S HD)1920 x 1080 (4:2:0, 8bit) (Approx.): 119.88p (100 Mbps / 60 Mbps), 100p (100 Mbps / 60 Mbps), 59.94p (50 Mbps / 25 Mbps), 50p (50 Mbps / 25 Mbps), 29.97p (50 Mbps / 16 Mbps), 25p (50 Mbps / 16 Mbps), 23.98p (50 Mbps), 1920 x 1080 (4:2:2, 10bit) (Approx.): 59.94p (50 Mbps), 50p (50 Mbps), 29.97p (50 Mbps), 25p (50 Mbps), 23.98p (50 Mbps)
MOVIE RECORDING FORMAT (XAVC S-I 4K)3840 x 2160 (4:2:2, 10bit) (Approx.): 29.97p (300 Mbps), 25p (250 Mbps), 23.98p (240 Mbps)
MOVIE RECORDING FORMAT (XAVC S-I HD)1920 x 1080 (4:2:2, 10bit) (Approx.): 59.94p (222 Mbps), 50p (185 Mbps), 29.97p (111 Mbps), 25p (93 Mbps), 23.98p (89 Mbps)
Movie Functions
PROXY RECORDINGYes
TC / UBYes
SLOW & QUICK MOTION (SHOOTING FRAME RATE)Yes
RAW OUTPUT-
Recording System
MEMORY CARD SLOTSlot for SD (UHS-I/II compliant) memory card
Focus System
FOCUS TYPEFast Hybrid AF (phase-detection AF / contrast-detection AF)
FOCUS SENSITIVITY RANGEEV-4 to EV20 (ISO 100 equivalent in AF-S)
FOCUS POINTStill images: Max. 693 points (phase-detection AF), Movies: Max. 693 points (phase-detection AF)
RECOGNITION TARGET (STILL IMAGES)Auto, Human, Animal, Bird, Insect, Car, Train, Airplane
RECOGNITION TARGET (MOVIES)Auto, Human, Animal, Bird, Insect, Car, Train, Airplane
AF ILLUMINATORYes (with Built-in LED type)
Exposure Control
METERING TYPE1200-zone evaluative metering
METERING SENSITIVITYEV-3 to EV20 (ISO 100 equivalent)
EXPOSURE COMPENSATION+/- 5.0 EV (1/3 EV steps)
ISO SENSITIVITYStill images: ISO 100 - 32000 (expandable to ISO 50 - 102400), AUTO (ISO 100 - 12800, selectable lower limit and upper limit),Movies: ISO 100 - 32000 equivalent2, AUTO (ISO 100 - 12800, selectable lower limit and upper limit)
ANTI-FLICKER SHOOT.-
Viewfinder
TYPE1.0 cm (0.39-type) electronic viewfinder (XGA OLED)
DIOPTRE-4.0 to +3.0 m-1
Viewfinder
MAGNIFICATIONApprox. 0.70x (with 50 mm lens equiv. at infinity, -1 m-1)
EYE POINTApprox. 22 mm from the eyepiece lens, 17.9 mm from the eyepiece frame at -1 m-1 (CIPA standard)
LCD Screen
MONITOR TYPE7.5 cm (3.0-type) type TFT
TOUCH PANELYes
NUMBER OF DOTS2 359 296 dots
ADJUSTABLE ANGLE-
Other Features
OTHER FEATURESSoft Skin Effect, Creative Look, Custom function, Picture Profile, My Image Style, Vertical Display
CLEAR IMAGE ZOOM (STILL IMAGES)-
CLEAR IMAGE ZOOM (MOVIES)Approx. 1.5x (4K), Approx. 2x (HD)
Shutter
SHUTTER TYPEMechanical shutter / Electronic shutter
SHUTTER SPEEDStill images (Mechanical shutter): 1/4000 to 30 s[fn_XX2], Bulb, Still images (Electronic shutter): 1/8000 to 30 s, Movies: 1/12800 to 1 s
FLASH SYNC. SPEED1/4000 s3
Image Stabilization
TYPEElectronic
MODEMovie: Active / Off
Flash
TYPE-
CONTROLPre-flash TTL
EXTERNAL FLASH COMPATIBILITYSony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash compatible with Auto-lock accessory shoe
Flash
FLASH COMPENSATION+/- 3.0 EV (1/3 EV steps)
Drive
CONTINUOUS DRIVE SPEED (APPROX. MAX.)Hi: 5.0 fps4
NO. OF FRAME RECORDABLE (APPROX.)JPEG Extra fine L: 120 frames4, JPEG Fine L: over 1000 frames4, JPEG Standard L: over 1000 frames4, RAW: 52 frames4, RAW & JPEG: 40 frames4, RAW (Lossless Compressed): 20 frames4, RAW (Lossless Compressed) & JPEG: 16 frames4, RAW (Uncompressed): 15 frames4, RAW (Uncompressed) & JPEG: 14 frames4
Playback
MODESEnlarge Image, Protect, Rating, Shot Mark (Movie), Divider Frame, Crop, Photo Capture
Accessibility
FUNCTIONSScreen reader, Focus Magnifier, Peaking Display, Subject Recognition in AF, Touch Focus, Touch Tracking, Touch Shutter, Touch AE, Custom function, Enlarge Menu Screen
Power
POWER CONSUMPTION WITH VIEWFINDERStill images: Approx. 3.2 W, Movies: Approx. 5.5 W
Interface
PC INTERFACEMass-storage / MTP
USB TYPE-C TERMINALYes (SuperSpeed USB 5 Gbps (USB 3.2) compatible)
WIRELESS LAN（BUILT-IN）Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac (2.4 GHz band/5 GHz band))5
BLUETOOTHYes (Bluetooth Standard Ver. 4.2 (2.4 GHz band))
HDMI OUTPUTHDMI micro connector (Type-D), 3840 x 2160 (29.97p / 25p / 23.98p) / 1920 x 1080 (59.94p / 50p / 23.98p) / 1920 x 1080 (59.94i / 50i), YCbCr 4:2:2 10bit / RGB 8bit
MULTI INTERFACE SHOEYes (with Digital Audio Interface)
MIC TERMINALYes (3.5 mm Stereo minijack)
REMOTE CONTROL (WIRELESS)Yes (Bluetooth remote control)
FUNCTIONSSend to smartphone, Remote control via smartphone, Remote Shooting
Interface
HEADPHONE TERMINAL-
USB Streaming
VIDEO DATA FORMAT-
VIDEO RESOLUTION-
AUDIO DATA FORMAT-
Audio
MICROPHONEBuilt-in, stereo
SPEAKERBuilt-in, monaural
Lens Compensation
SETTINGShading, Chromatic Aberration, Distortion
Power
SUPPLIED BATTERYOne rechargeable battery pack NP-FW50
USB POWER SUPPLYYes (Available with USB Type-C terminal. USB Power Delivery compatible)
BATTERY LIFE (STILL IMAGES)Approx. 270 shots (Viewfinder) / Approx. 300 shots (LCD monitor) (CIPA standard)6
BATTERY LIFE (MOVIE, ACTUAL RECORDING)Approx. 50 min (Viewfinder) / Approx. 50 min (LCD monitor) (CIPA standard)7
BATTERY LIFE (MOVIE, CONTINUOUS RECORDING)Approx. 80 min (Viewfinder) / Approx. 80 min (LCD monitor) (CIPA standard)
INTERNAL BATTERY CHARGEYes (Available with USB Type-C terminal. USB Power Delivery compatible)[fn_xx3]
POWER CONSUMPTION WITH LCD SCREENStill images: Approx. 2.9 W, Movies: Approx. 5.5 W
Size & Weight
WEIGHT (WITH BATTERY AND MEMORY CARD INCLUDED)Approx. 498 g / Approx. 1 lb 1.6 oz
BODY ONLYApprox. 454 g /Approx. 1 lb 0.1 oz
DIMENSIONS (W X H X D)Approx. 113.3 x 67.9 x 87.5 mm, Approx. 113.3 x 67.9 x 74.5 mm (from front of lens to monitor) / Approx. 4 1/2 x 2 3/4 x 3 1/2 inches, Approx. 4 1/2 x 2 3/4 x 3 inches (from front of lens to monitor)
Operating temparature
OPERATING TEMPERATURE0 - 40 ℃ / 32 - 104 °F
Supplied Accesory
WHAT'S IN THE BOXRechargeable Battery NP-FW50, Lens cap, Accessory shoe cap, Eyepiece cup, Shoulder strap, Wrapping Cloth
